Traffic lights simulator (with EID210) – Practical works manual (ref: EID212041)
Topics & solutions for the EID210 board are provided with the practical works manual, many topics are studied, from the basic crossroads to the hight traffic crossroads (main road, side road).
In the first example, a basic crossroads then a left stacking lane are studied.
Analysis, source programs (“assembler” and “C”) are provided in paper form and on a CD-ROM.
Details of the practical works:
▪ Basic cycle: WITHOUT pedestrian calls, WITHOUT car detection.
▪ Complete cycle: WITHOUT pedestrian calls, WITHOUT car detection.
▪ Complete cycle: WITH pedestrian calls, WITHOUT car detection.
▪ Complete cycle: WITHOUT pedestrian calls, WITH car detection process.
